Modifications reserved Page 46/99
OPM_SPE_XXX_10K_40K_8GB_V020.doc Operating Manual SitePro 10-15-20-30-40 kVA / S8
7.2 METERING
The METERING mode is entered any time the “METER” key is pressed.
The LCD screen will indicate a series of screenshots showing the measures of all electric parameters like
AC, DC and various statistics.
In this mode the keys perform the following functions:
Return to HOME screen.
Scrolls backward to the previous screen.
Scrolls forward to the next screen.
It is possible to view any key functional description by pushing the key for more than 3 seconds.
`Home\Meter
BATTERY
V 409 V
I 5.0 A
T +25° C
Charge level 80 %
Autonomy 12 Min
Battery data screen
V The battery voltage.
I The battery current (negative values correspond to
the discharge of the battery).
T The temperature of the battery (“SENSOR DISABLE”
indicates sensor disabled).
Charge level The battery charge level.
Autonomy The estimated backup time with the
present load.
`Home\Meter
RECTIFIER
f :
393 V Idc2 : 0.0 A
Rectifier mains data screen
f The input frequency of the rectifier.
L12
L23 The voltage levels between the three phases (line-
L31 to-line).
Vdc Rectifier voltage output.
Idc1 Output current rectifier bridge.
Idc2 Output current 2
nd
Rectifier Bridge (optional 12
pulse Rectifiers only).
`Home\Meter
MAINS
f 50 Hz
L1 230 V
L2 229 V
L3 231 V
BYPASS FREE
Bypass mains data screen
f The frequency of the mains.
L1
L2 3-phase mains voltage PHASE /NEUTRAL.
L3
Bypass Bypass status: FREE / LOCKED.
To Next Page
