Modifications reserved Page 92/99
OPM_SPE_XXX_10K_40K_8GB_V020.doc Operating Manual SitePro 10-15-20-30-40 kVA / S8
10.4 DISPOSITION OPTIONS
1A = SitePro 10, 15, 20, 30 kVA
1B = SitePro 40 kVA
2 = 12 pulses rectifier with or without
galvanic isolation
3 = Battery cabinet 500 mm / 19.68”
4 = Battery cabinet 750 mm / 29.53”
5 = Battery cabinet 1100 mm /
43.30”
The following table shows the weights in kg / lbs of the most common configurations:
UPS
standard
without
battery
Rectifier
and/or
bypass
transformer
in UPS
cabinet
Input filter
5
th
harmonic
in UPS
cabinet
12 pulses
rectifier
without
galvanic
isolation in
additional
cabinet
12 pulses
rectifier
with
galvanic
isolation in
additional
cabinet
Empty
Battery
Cabinet
1 = 500 mm
2 = 750 mm
3 = 1100 mm
UPS
Model
(1) (1) (1) / (2) / (3)
10 kVA
285 kg
629 lbs
70 kg
155 lbs
20 kg
44 lbs
15 kVA
285 kg
629 lbs
70 kg
155 lbs
20 kg
44 lbs
20 kVA
285 kg
629 lbs
110 kg
243 lbs
40 kg
88 lbs
30 kVA
340 kg
673 lbs
145 kg
320 lbs
40 kg
88 lbs
Not
available
Not
available
40 kVA
340 kg
750 lbs
195 kg
430 lbs
40 kg
88 lbs
225 kg
497 lbs
305 kg
673 lbs
95/140/200 kg
210/309/441 lbs
Single weights have to be added up for system configuration to get the total weight!
For additional options refer to the technical data sheet in section annexe.
