Special Functions
Temperature Compensation
This function allows you the capability to adjust the temperature compensation oset of any indoor unit. The adjusted value is
programmed into the EEPROM.
Guide 1
1. Install the grille assembly and connect the power cable.
2. Unplug the wired controller.
3. Connect power to the unit.
4. Press the ON/OFF button on the remote control (HBS-01).
5. (Ignore this step if the display temperature is already
O
C,) Press MENU/OF button to switch the display temperature to
O
C,
then press conrm.
6. Open the front cover of the remote controller, and press the LIGHT button 12 times in 7 seconds.
7. The panel will beep 4 times and display an “A”.
8. Press the LIGHT button once to conrm. The display will read “A0”.
9. Press the button TEMP. or TEMP. until the display shows “A5”.
10. Press the LIGHT button once to conrm. The display will read “0b”.
11. Press the button TEMP. or TEMP. to scroll through the listed
Codes. Each code is associated with a corresponding compensation
value (see table below). For example, if you want make the
temperature invalid, scroll it to 0F.
12. Press the LIGHT button once to conrm. The display will read “A5”.
13. Press the ON/OFF button on the remote control to save the changes.
Series IDU
IDU PCB part number Controls Needed
Guide
Reference
Haier GEA Controller IR Reciever Wired Controller
3X3 Cassette AL24LP2VHA 0151800208 WJ26X23559 YR-HBS01 \ Unplug 1
2X2 Cassette AB09SC2VH* 0151800208A WJ26X23785 YR-HBS01 \ Unplug 3
2X2 Cassette AB12SC2VH* 0151800208A WJ26X23785 YR-HBS01 \ Unplug 3
2X2 Cassette AB18SC2VH* 0151800208A WJ26X23785 YR-HBS01 \ Unplug 3
Mid-Static Duct USYM09UCDSA 0151800580 WJ26X27175 YR-HG RE-02(CN29) Unplug 4
Mid-Static Duct USYM12UCDSA 0151800580 WJ26X27175 YR-HG RE-02(CN29) Unplug 4
Mid-Static Duct USYM18UCDSA 0151800580 WJ26X27175 YR-HG RE-02(CN29) Unplug 4
Mid-Static Duct USYM24UCDSA 0151800580 WJ26X27175 YR-HG RE-02(CN29) Unplug 4
Slim Duct AD07SL2VH* 0151800175A WJ26X23178 YR-HBS01 RE-02(CN29) Unplug 2
Slim Duct AD09SL2VH* 0151800175A WJ26X23178 YR-HBS01 RE-02(CN29) Unplug 2
Slim Duct AD12SL2VH* 0151800175A WJ26X23178 YR-HBS01 RE-02(CN29) Unplug 2
Slim Duct AD18SL2VH* 0151800175A WJ26X23178 YR-HBS01 RE-02(CN29) Unplug 2
Highwall ASYW07URDWA A0011001066 WJ26X25213 YR-HG \ \ 4
Highwall ASYW09URDWA A0011001066 WJ26X25213 YR-HG \ \ 4
Highwall ASYW12URDWA A0011001066 WJ26X25213 YR-HG \ \ 4
Highwall ASYW18URDWA A0011007590 WJ26X25413 YR-HG \ \ 4
Console USYF09UCDWA 0151800579 WJ26X27223 YR-HG \ \ 4
Console USYF12UCDWA 0151800579 WJ26X27223 YR-HG \ \ 4
Console USYF18UCDWA 0151800579 WJ26X27223 YR-HG \ \ 4
