MID-STATIC DUCTED TECHNICAL OVERVIEW
ENGLISH
Topic Title
G-11
Testing
3. Feed motor wires into the air inlet box
4. Remove the air box cover.
5. Remove the corner bracket.
6. Remove the ground screw and free the motor wire
harness.
7. Remove the screws holding the blower housing to the unit,
4 on each housing.
8. Support the motor (2 people may be required at this time).
Loosen the 2 screws of the motor mount bracket and
remove full assembly
9. Using a long 4mm hex wrench, loosen the set screws from
the blower wheel and remove from motor shaft.
Replacing WiFi Module
1. Unplug existing WiFi module.
2. Insert new WiFi module.
3. Replace the wi passcode sticker.
4. Pair the unit to account.
