2 - 2 Section 2-2 - General console requirements
Section 2-2
General console requirements
2-2-1 Environmental Requirements
2-2-1-1 Cooling
The cooling requirement for the LOGIQ S8 is 680 BTU/hr. This figure does not include cooling needed
for lights, people, or other equipment in the room.
Each person in the room places an additional 300 BTU/hr. demand on the cooling system.
2-2-1-2 Lighting
Bright light is needed for system installation, updates and repairs. However, operator and patient
comfort may be optimized if the room light is subdued and indirect. Therefore a combination lighting
system (dim/bright) is recommended. Keep in mind that lighting controls and dimmers can be a source
of EMI which could degrade image quality. These controls should be selected to minimize possible
interference.
Table 2-1 System Environmental Requirements
Operational Storage Transport
Temperature
10 - 35
o
C /50 - 95
o
F -10 - 50
o
C/14 - 122
o
F -10 - 50
o
C/14 - 122
o
F
Humidity 30 - 80% (non-condensing) 10 - 90% (non-condensing) 10 - 90% (non-condensing)
Pressure 700 - 1060 hPa 700 - 1060 hPa 700 - 1060 hPa
Heat Dissipation 680BTU/hr n/a n/a
