GE M-Pact Plus User Manual

B.19
M-PACT Plus
Accessories
A
B
C
X
(1) Reference is for one cable
Frame 1 & 2
Type A: order 1 interlock kit and 1 cable per ACB
Type B: order 1 interlock kit and 2 cable per ACB
Type C: order 1 interlock kit and 2 cable per ACB
Type D: order 1 interlock kit and 1 cable per Supply breaker plus 1 interlock kit for the Control breaker and 2 cables
For type D configuration 2 Supply Breakers and one Control Breaker are required.
Cable for interlock
Length Cat. no. Ref. No.
(1)
1.0 meter 100BCMCI
405531
1.6 meter 160BCMCI
405532
2.0 meter 200BCMCI
405533
2.5 meter 250BCMCI
405610
3.0 meter 300BCMCI
405611
3.5 meter 350BCMCI
405612
4.0 meter 400BCMCI
405613
Type D - 1 from 3 way interlock/cable - Supply Breakers Type D - 1 from 3 way interlock/cable - Control Breaker
Frame size Version Poles Cat. no. Ref. No. Cat. no. Ref. No.
1 Withdrawable 3 D13WCI3PW
406366
D13WCI3PWCON
406966
4 D13WCI4PW
406367
D13WCI4PWCON
406967
Fixed 3 D13WCI3PF
406364
D13WCI3PFCON
406968
4 D13WCI4PF
406365
D13WCI4PFCON
406969
2 Withdrawable 3 D13WCIF23PW
405511
D13WCIF23PWCON
406970
4 D13WCIF24PW
405513
D13WCIF24PWCON
406971
Fixed 3 D13WCIF23PF
405515
D13WCIF23PFCON
406972
4 D13WCIF24PF
405517
D13WCIF24PFCON
406973
Type C - 2 from 3 way interlock / Cable
Frame size Version Poles Cat. no. Ref. No.
1 Withdrawable 3 C23WCI3PW
406358
4 C23WCI4PW
406359
Fixed 3 C23WCI3PF
406356
4 C23WCI4PF
406357
2 Withdrawable 3 C23WCIF23PW
405491
4 C23WCIF24PW
405493
Fixed 3 C23WCIF23PF
405495
4 C23WCIF24PF
405497
Mechanical accessories
Type A - 2 way interlock / Cable Type B - 1 from 3 way interlock / Cable
Frame size Version Poles Cat. no. Ref. No. Cat. no. Ref. No.
1 Withdrawable 3 2WCI3PW
406342
B13WCI3PW
406350
4 2WCI4PW
406343
B13WCI4PW
406351
Fixed 3 2WCI3PF
406340
B13WCI3PF
406348
4 2WCI4PF
406341
B13WCI4PF
406349
2 Withdrawable 3 2WCIF23PW
405459
B13WCIF23PW
405475
4 2WCIF24PW
405461
B13WCIF24PW
405477
Fixed 3 2WCIF23PF
405463
B13WCIF23PF
405479
4 2WCIF24PF
405465
B13WCIF24PF
405481
Interlocks Miscellaneous
Frame Item Cat. no. Ref. No. Frame Item Cat. no. Ref. No.
size size
1, 2
Castell key breaker interlock (supplied loose)
(1)
CASLOK
405570
1, 2
Operations counter MOC
405576
Fortress key breaker interlock (supplied loose)
(1)
FORLOK
405569
Left hand door interlock - hinged right DILHS
405578
Profalux key breaker interlock (supplied loose)
(1)
PROLOK
405572
Right hand door interlock - hinged left DIRHS
405579
Profalux key cassete interlock (supplied loose)
(1)
PROCAS
405574
Mis-insertion device (factory fi tted) ACBMID
405605
Ronis key breaker interlock (factory fi tted)
(2)
RONLKEY
406335
Mis-insertion device (supplied loose) ACBMIL
405505
Ronis key breaker interlock (supplied loose)
(2)
RONWKEY
406338
IP54 door IP54DOOR
405606
Ronis key breaker interlock (supplied loose)
(1)
RONLOK
405571
Handling (lifting) truck ACBLIFT
405607
Ronis key cassete interlock (factory fi tted)
(2)
RONWKEYFF
406339
Spare or replacement racking handle MPRACKHAN
406393
Ronis key cassete interlock (supplied loose)
(1)
RONCASNK
406337
Ronis key cassete interlock (factory fi tted)
(1)
RONCAS
405573
(1) Without lock and key
(2) With lock and key
