GE M-Pact Plus User Manual

A.6
Technical overview
A
B
C
X
M-PACT Plus
The fi gures specifi ed apply to withdrawable ACB's with fl at face vertical
copper connections
(1) Protection degree IP00.For use in enclosures with interior temperatures
of 40° to 70° the relevant IP values can be applied.
Down-stream
- 400 800 1000 1250 1600 2000 2500 3200 4000
400---------
800 Full --------
1000 Full --------
1250 Full Full -------
1600 Full Full Full - - - - - -
2000 Full Full Full Full - - - - -
2500 Full Full Full Full Full Full - - -
3200 Full Full Full Full Full Full - - -
4000 Full Full Full Full Full 2000 Full - -
Up-stream
Ambient
Temperature
Current Rating (A)
800 1000 1250 1600 2000 2500 3200 4000
50°C 800 1000 1250 1600 2000 2450 3200 3727
60°C 800 1000 1250 1445 2000 2232 3200 3367
65°C 800 1000 1250 1364 2000 2092 3019 3175
70°C 800 1000 1250 1280 1970 1970 2831 2978
Selectivity
The following table shows the conditions to satisfy full
selectivity between UP-STREAM and DOWN-STREAM devices.
Up-stream: M-PACT Plus
Down-stream: M-PACT Plus
ST delay 50 ms minimum between up-stream and downstream
ACB Multiplication coeffi cient between LT-ratings ≥ 1,56
Temperature Deratings
Free Air
(1)
The M-PACT Plus ACBs may operate at higher ambient
temperatures than 40°C in certain installation conditions.
In this case the current rating in Amperes should be reduced
as indicated below.
Characteristics
Performance data
Characteristics Symbol
Units
Rated current (40°C) In
A
400 630 800 1000
Endurance (n° of operating cycles)
20000 20000 20000 20000
Mechanical (with maintenance)
10000 10000 10000 10000
Mechanical (without maintenance)
5000 5000 5000 5000
Electrical (at rated current)
690 690 690 690
Rated service voltage (50/60 Hz) Ue
V
1000 1000 1000 1000
Rated insulation voltage Ui
V
8000 8000 8000 8000
Rated impulse withstand voltage Uimp
V
3 & 4 3 & 4 3 & 4 3 & 4
Number of poles
100% 100% 100% 100%
Rating of 4th pole
ACB type SNSNSNHSNH
Frame size 1 1 1 1 1 1 2 1 1 2
Rated ultimate short-circuit Icu
kA (rms)
Breaking capacity 220V
50 65 50 65 50 65 80 50 65 80
415V
50 65 50 65 50 65 80 50 65 80
500V
50 65 50 65 50 65 80 50 65 80
600V
50 50 50 50 50 50 65 50 50 65
690V
40 40 40 40 40 40 60 40 40 60
Rated service short-circuit Ics
kA (rms)
Breaking capacity 220V
50 65 50 65 50 65 80 50 65 80
415V
50 65 50 65 50 65 80 50 65 80
500V
50 65 50 65 50 65 80 50 65 80
600V
50 50 50 50 50 50 65 50 50 65
690V
40 40 40 40 40 40 60 40 40 60
Rated short time withstand current
1 second Icw
kA (rms)
50 65 50 65 50 65 80 50 65 80
3 seconds Icw
kA (rms)
40 50 40 50 40 50 50 40 50 50
Rated short-circuit 415V
kA (peak)
143 143 143 143 143 143 176 143 143 176
making capacity 500V
143 143 143 143 143 143 176 143 143 176
600V
143 105 143 105 143 105 143 105 105 143
690V
84 84 84 84 84 84 105 84 84 105
Power dissipation at In (fixed breaker) W
Watt
16 11 39 27 63 43 23 106 68 36
Power dissipation at In (withdrawable) W
Watt
33 22 75 53 127 86 49 211 135 77
Design and specifications are subject to changes without notice.
