GE M-Pact Plus User Manual

C.6
Dimensional drawings
A
B
C
X
M-PACT Plus
Horizontal, rear access connection
Fixed pattern
Type S, N - 3 pole - Frame size 2, In=3200A to 4000A
Type H - 3 pole - Frame size 2, In=800A to 4000A
Type S, N - 4 pole - Frame size 2, In=3200A to 4000A
Type H - 4 pole - Frame size 2, In=800A to 4000A
100 to door
100 to door
Centre line of operating panel
Centre line of operating panel
Centre line of
operating panel
Centre line of
operating panel
Copperwork must be supported within 200 mm of breaker
connections-busbars or cables. All connections to be tightened to 50Nm.
Copperwork must be supported within 200 mm of breaker
connections-busbars or cables. All connections to be tightened to 50Nm.
Minimum space to earth metal
and for arc chute removal
Minimum space to earth metal
and for arc chute removal
Insulated metal or insulated
sheet (customer supplied)
Insulated metal or insulated
sheet (customer supplied)
