GE M-Pact Plus User Manual

A.7
M-PACT Plus
Characteristics
A
B
C
X
Dimensions in mm
Frame
Size
Rating
(A)
Poles Type Height
(1)
Width Depth
(2)
1 400 to 2500 3 Withdrawable 440 329 422
Fixed 430 342 352
4 Withdrawable 440 429 422
Fixed 430 442 352
2 800 to 4000 3 Withdrawable 440 419 424
Fixed 430 432 352
4 Withdrawable 440 549 424
Fixed 430 562 352
Weights (kg)
S range N range H range
Fixed pattern Frame 3 Pole 4 Pole 3 Pole 4 Pole 3 Pole 4 Pole
400 to 1600A 1 39 49 39 49 / /
2000 to 2500A 1 43 54 43 54 / /
800 to 3200A 2 53 68 53 68 53 68
4000A 2 53 68 53 68 53 68
Withdrawable Frame 3 Pole 4 Pole 3 Pole 4 Pole 3 Pole 4 Pole
400 to 1600A 1 68 79 68 79 / /
2000 to 2500A 1 74 85 74 85 / /
800 to 3200A 2 90 109 90 109 90 109
4000A 2 113 128 113 128 113 128
MS31F16
Ratings:
04-400A, 08-800A
10-1000A, 12-1250A
16-1600A, 20-2000A
25-2500A, 32-3200A
40-4000A
Installation: F-fi xed, W-withdrawable
Type: 1-Frame1, 2-Frame2
* Letter 'L' & 'R' only for type selection, not shown on nameplate.
Breaking Capacity: S, N, H
M-PACT Plus
Pole: 3-3P
4-4P*
Recommended Minimum Copper Size
In accordance with IEC 60947-2
Rating (A) Copper / phase
400 2 x 50 x 5
800 2 x 50 x 5
1000 2 x 60 x 5
1250 2 x 100 x 5
1600 2 x 100 x 5
2000 3 x 100 x 5
2500 4 x 100 x 5
3200 4 x 100 x 10
4000 4 x 100 x 10 + 1 x 100 x 5
(1) Height is from mounting surface to highest part of the ACB.
(2) Depth is from the cubicle door to the back of terminals.
* 4P, Neutral on the left or right Please specify on selection form,the default
option is Neutral on right.
Catalogue Number Confi guration
1200 1600 2000 2500 3200 4000
20000 20000 20000 20000 20000 20000
10000 10000 10000 10000 10000 10000
5000 5000 5000 5000 5000 5000
690 690 690 690 690 690
1000 1000 1000 1000 1000 1000
8000 8000 8000 8000 8000 8000
3 & 4 3 & 4 3 & 4 3 & 4 3 & 4 3 & 4
100% 100% 100% 100% 100% 100%
SNHSNHSNHSNHSNHSNH
1 1 2 1 1 2 1/2 1/2 2 1/2 1/2 2 2 2 2 2 2 2
50 65 80 50 65 80 50 65 80 50 65 80 50 65 80 50 65 80
50 65 80 50 65 80 50 65 80 50 65 80 50 65 80 50 65 80
50 65 80 50 65 80 50 65 80 50 65 80 50 65 80 50 65 80
50 50 65 50 50 65 50 50 65 50 50 65 50 50 65 50 50 65
40 40 60 40 40 60 40 40 60 40 40 60 40 40 60 40 40 60
50 65 80 50 65 80 50 65 80 50 65 80 50 65 80 50 65 80
50 65 80 50 65 80 50 65 80 50 65 80 50 65 80 50 65 80
50 65 80 50 65 80 50 65 80 50 65 80 50 65 80 50 65 80
50 50 65 50 50 65 50 50 65 50 50 65 50 50 65 50 50 65
40 40 60 40 40 60 40 40 60 40 40 60 40 40 60 40 40 60
50 65 80 50 65 80 50 65 80 50 65 80 50 65 80 50 65 80
40 50 50 40 50 50 40 50 50 40 50 50 40 50 50 40 50 50
143 143 176 143 143 176 143 143 176 143 143 176 143 143 176 143 143 176
143 143 176 143 143 176 143 143 176 143 143 176 143 143 176 143 143 176
143 105 143 143 105 143 143 105 143 143 105 143 143 105 143 143 105 143
84 84 105 84 84 105 84 84 105 84 84 105 84 84 105 84 84 105
175 105 60 287 196 98 224 224 163 224 224 163 418 418 418 571 571 571
351 211 128 574 392 209 490 490 347 490 490 347 888 888 888 1224 1224 1224
