3-4 MAC 1200 resting ECG analysis system Revision D
2012250-095
System Test Function: Test Start
Test Start
After simultaneously pressing the keys Shift + 12 Lead (or Auto), the initial display
menu appears, so you can select a specific test. The specific test functions are
activated by pressing the corresponding key.
Table 1. Hardware Tests
International version
1
1. Applies to all device variants except US and Pharma.
US version
2
2. Applies to US and Pharma device variants.
Key Test Performed Key Test Performed
1 Display test 1 Display test
2 Keyboard 2 Keyboard
3 Motor test 3 Motor test
4 Test results 4 Test results
5 Recording test 5 Recording test
6 V24 tests 6 V24 tests
7 Time and date 7 Time and date
8 Electrode test 8 Electrode test
D Device model D Device model
H Interpretation N Serial number
N Serial number O ACI-TIPI
O
Ergometer/Treadmill
3
3. Applies to Japan device variant.
X End (Terminate hardware tests)
X End (Terminate hardware tests)
