3-18 MAC 1200 resting ECG analysis system Revision D
2012250-095
System Test Function: Interpretation (International Device Models Only)
Interpretation (International Device Models Only)
Switching over the program for interpretation is activated by pressing the H key, the
following display image appears:
The currently enabled interpretation program appears in reverse video.
WARNING
Switching over to another program for Interpretation affects the
measurement results and the interpretation.
The program for Interpretation configured during manufacture should only be
changed when deemed really necessary.
The required program for Interpretation is selected by pressing the appropriate key,
1 or 2.
Quit the selection menu by pressing the X key. Quit the self-test with the X key.
MAC 1200 resting ECG analysis system configures the appropriate items and
initiates a cold start automatically. Thus, when the device is rebooted automatically
all the new settings are adopted.
NOTE
When configuring the device model, saved ECGs are not lost.
When printing the saved ECGs, the display in the status line is related to the
currently enabled program for interpretation, although the results are based on
the program previously configured.
In this case the saved ECGs should be printed out or transferred to a PC before
switching over to the new program for interpretation.
Table 11. Interpretation
1 HEART
2 12SL
X End
