Revision D MAC 1200 resting ECG analysis system 3-7
2012250-095
System Test Function: Motor Test
Motor Test
When the 3 key is pressed, the following menu appears.
Terminate with any key.
The speed select key is used to set the required speed and the motor is set into
motion with Start/Stop.
A marking pulse is set once every second. The running speed can then be calculated
or its accuracy checked from the distance between marking pulses. Pressing a key
that is not included in this menu will return you to the initial display menu.
Table 4. Motor Speed Test
Key Test Performed
Format/Speed Speed selection motor
Start/Stop Start/Stop motor
