SecoGear – Installation, Operation and Maintenance Manual 14 of 56
Lift sling
Lifting plates must
be removed where
sections are joined,
during installation
Front view
Side view
Roller
Figure 2-2: Recommended Lifting Method (Side View)
Figure 2-4: Placing Forklift Tines under Equipment Shipping Skid
Figure 2-5: Method of Moving
Figure 2-3: Corner Warning Label
When using a forklift to raise the lineup, proceed as follows:
1. Expand forklift tines to their maximum (widest) extension.
2. Carefully insert tines of forklift below one side of the enclosure
at the approximate center of the panel as shown in Figure 2-4.
3. Raise equipment and proceed to transport the enclosure.
4. Carefully lower the enclosure until it rests stable at its
final destination.
After shipping skids are removed, roller may be used to roll
equipment parallel to front only.
Using Rollers
Forklifts
