APPENDIX
Display Default CONF Description
Menu
MAIN
PU / SU / F -
Set.P 0 Local Setpoint
SP.1 100 Setpoint 1
SP.2 200 Setpoint 2
In.1 - Input IN1 main
In.2 - Input IN2 main
In.3 - Input IN3 auxiliary
In.4 - Input IN4 auxiliary
Fin.A - Result math function A
Fin.b - Result math function b
(i.A Coefficient math function A
(i.b Coefficient math function B
AL.1 100 Alarm 1 setpoint
AL.2 200 Alarm 2 setpoint
AL.3 300 Alarm 3 setpoint
AL.4 400 Alarm 4 setpoint
AL.5 500 Alarm 5 setpoint
AL.6 600 Alarm 6 setpoint
AL.7 700 Alarm 7 setpoint
AL.8 800 Alarm 8 setpoint
AL.9 900 Alarm 9 setpoint
AL.10 1000 Alarm 10 setpoint
A.Pid - PID group active
0vtP - PID power
(0.1 - Control output 1
(0.2 - Control output 2
Menu Inf
Upd - Software release
(od - Instrument code
Err.1 - Error code for IN1
Err.2 - Error code for IN2
Err.3 - Error code for IN3
Err.4 - Error code for IN4
Err.5 - Error code for Fin. A
Err.6 - Error code for Fin. b
dps.s - Decimal point position Fin. A
dps.6 - Decimal point position Fin. b
Lo.S.5 - MIN scale limit Fin. A (read only)
Lo.S.6 - MIN scale limit Fin. b (read only)
xiS.S - MAX scale limit Fin. A (read only)
xiS.6 - MAX scale limit Fin. b (read only)
Upd.F - Fieldbus software version
(od.F - Fieldbus instrument code (read only)
bAv.F - Fieldbus Set Baudrate (read only)
Menu
(FG.Pd
S.tv 0 Type of Tuning
n.Pid 1 Number of PID groups
t.Pid 0 Type of variable for activation of PID parameter groups
Pb.1 100.0 Proportional band, group 1
It.1 4.0 Integral time, group 1
dt.1 0.0 Derivative time, group 1
PrS.1 0.0 Reset power, group 1
UAL.1 100 Activation setpoint group 1
Pb.2 100.0 Proportional band, group 2
It.2 4.0 Integral time, group 2
dt.2 0.0 Derivative time, group 2
PrS.2 0.0 Reset power, group 2
UAL.2 200 Activation setpoint group 2
Pb.3 100.0 Proportional band, group 3
It.3 4.0 Integral time, group 3
dt.3 0.0 Derivative time, group 3
PrS.3 0.0 Reset power, group 3
UAL.3 300 Activation setpoint group 3
