gefran BDI50 Series User Manual

Appendix-2 Instructions for UL
App 2-3
Closed-Loop Crimp Terminal Size
Drive Model
Wire Gauge
Terminal Crimp Terminal Tool Insulation Cap
mm
2
, (AWG)
BDI50 R/L1  S/L2  T/L3 U/T1  V/T2  W/T3 Screws Model No. Machine No. Model No.
1004
1.3 (16)
M3.5
R2-3.5
Nichifu NH 1 / 9
TIC 2
1007
2.1 (14)
M3.5
R2-3.5
Nichifu NH 1 / 9
TIC 2
2015
3.3 (12)
M4
R3.5-4
Nichifu NH 1 / 9
TIC 3.5
2022 5.3 (10) M4 R5.5-4 Nichifu NH 1 / 9 TIC 3.5
3037
5.3 (10)
M4
R5.5-4
Nichifu NH 1 / 9
TIC 5.5
4055
4075
8.4 (14) M5 R8-5 Nichifu NH 1 / 9 TIC 8
2007
2.1 (14)
M4
R3.5-4
Nichifu NH 1 / 9
TIC 2
2015
2.1 (14)
M4
R3.5-4
Nichifu NH 1 / 9
TIC 2
2022 2.1 (14) M4 R3.5-4 Nichifu NH 1 / 9 TIC 2
3037
2.1 (14)
M4
R2-3.5
Nichifu NH 1 / 9
TIC 2
3055
4075
4110
8.4 (8) M5 R8-5 Nichifu NH 1 / 9 TIC 8
◆Type 1
During installation, all conduit hole plugs shall be removed, and all conduit holes shall be used.
Recommended Input Fuse Selection
Fuse Type
Drive Model
BDI50-…-2M
Manufacturer: Bussmann
Model
Fuse Ampere Rating (A)
200 V Class Single-Phase Drives
1004
Bussmann 10CT/16CT
690V 10A / 690V 16A
1007
Bussmann 16CT/20CT
690V 16A / 690V 20A
2015
Bussmann 30FE
690V 30A
2022
Bussmann 50FE
690V 50A
Fuse Type
Drive Model
BDI50-…-2T
Manufacturer: Bussmann
Model
Fuse Ampere Rating (A)
200 V Class Three-Phase Drives
1007
Bussmann 10CT
690V 10A
2015
Bussmann 16CT
690V 16A
2022
Bussmann 20CT
690V 20A
3037
Bussmann 50FE
690V 50A
4055
Bussmann 63CT/100FE
690V 63A
4075
Bussmann 80CT/100FE
690V 80A/690V 100A
Fuse Type
Drive Model
BDI50-…-4
Manufacturer: Bussmann
Model
Fuse Ampere Rating (A)
400 V Class Three-Phase Drives
2007
Bussmann 10CT
690V10A
2015
Bussmann 16CT
690V 16A
2022
Bussmann 20CT
690V 20A
3037
Bussmann 25ET
690V 25A
3055
Bussmann 40FE
690V 40A
4075
Bussmann 50ET
690V 50A
4110
Bussmann 63ET
690V 63A
■ Field Wiring Terminals
All input and output field wiring terminals not located within the motor circuit shall be marked to indicate the proper connections
that are to be made to each terminal and indicate that copper conductors, rated 80°C are to be used.
