20 VDL200 • Quick installation guide - Specifications and connection
5.5 EMC Filter (optional)
The VDL200-...-F-4
Size Type Code
Dimensions:
W x H x d (mm)
Weight
(kg)
Conducted emissions according to / Motor
cable length
VDL200-... , 3ph
1040 EMI-FTF-480-7 S7GHL 190 x 40 x 70 0.6
EN 12015 / 10 m1055 EMI-FTF-480-16 S7GHO 250 x 45 x 70 0.8
2075 EMI-FTF-480-16 S7GHO 250 x 45 x 70 0.8
2110 EMI-FTF-480-30 S7GHP 270 x 50 x 85 1
EN 12015 / 10 m
3150 EMI-FTF-480-30 S7GHP 250 x 50 x 85 1
3185 EMI-FTF-480-42 S7GOA 310 x 50 x 85 1.3
3220 EMI-FTF-480-42 S7GOA 310 x 50 x 85 1.3
