A.5.5 Dimensions and weights
The equipment is packed in three wooden crates containing all
parts and accessories.
a) for Orthoralix 9200/Plus/Ceph
Crate (1) Column and counterweights:
PACKING DIMENSIONS 2350 x 300 x 550
PACKING WEIGHT 163 Kg
NET WEIGHT 121 K
Crate (2) Z-carriage, Tubehead and covers:
PACKING DIMENSIONS 1050 x 700 x 900
PACKING WEIGHT 130 Kg
NET WEIGHT 74 K
Crate (3) Ceph arm:
PACKING DIMENSIONS 1350 x 600 x 600
PACKING WEIGHT 55 Kg
NET WEIGHT 20 K
For the system dimensions see A-13.
b) for Orthoralix DDE/Ceph
Crate (1) Column and counterweights:
PACKING DIMENSIONS 2350 x 300 x 550
PACKING WEIGHT 163 Kg
NET WEIGHT 121 Kg
Crate (2) Z-carriage, Tubehead and covers:
PACKING DIMENSIONS 1050 x 700 x 900
PACKING WEIGHT 130 Kg
NET WEIGHT 74 K
Crate (3) Ceph arm:
PACKING DIMENSIONS 1200 x 700 x 740
PACKING WEIGHT 64 Kg
NET WEIGHT 22 K
For the system dimensions see A-13.
A.5.6 IEC Classification
t$MBTT*
t5ZQF#
t0SEJOBSZFRVJQNFOUFODMPTFEFRVJQNFOUXJUIPVUQSPUFDUJPO
against ingress of liquids)
t&RVJQNFOUGPSVTFJOFOWJSPONFOUTXIFSFOPGMBNNBCMFBO-
aesthetics and/or flammable cleaning agents are present.
t&RVJQNFOUGPSDPOUJOVPTPQFSBUJPOXJUIJOUFSNJUUFOUMPBEJOH
A.5.7 Applicable standards
For a list of the applicable National and International Standards,
please refer to the Operator’s Manual.
A.5.8 Accessories and special tools
The following accessories and tools are delivered with the system
(one piece each):
t$IJOSFTUDPEF
t#JUFCMPDLDPEF
t*NBHFRVBMJUZQIBOUPNDPEF
t$IJOSFTUGPS5.+DPEF
t,JUUFNQMBUFGPSUSBOTDBOTFF2MJTUGPSDPEFT
while the following are available on request from the Service
department:
t-JHIUCFBNQIBOUPNDPEF
A.5.9 Film cassettes
Film cassettes available:
TYPE NUMBER APPLICATION DIMENSIONS
9868 820 00349 Pan exposures 15 X 30 cm
9868 820 09039 Ceph 18 x 24 cm
9868 820 09249 Ceph “8”x10”
The cassette slot for Ceph projection can also accomodate 24 x
30 cm cassettes (not supplied).
