B.9 Check list
The following parts are included in the delivery:
Column
Counterweight 2
Bolts for wall fixation 6
Additional bracket for wall fixation 4
Nuts M10 4
Lock washer 4
Z-Carriage
Front cover with mirror 1
Top cover 1
Cassette driver cover 1
Chin rest 1
Chin rest for TMJ 1
Alignment tool for TMJ 1
Bite block 1
Hygienic bags for bite block 100
Knob 2
Image quality phantom 1
Exposure handswitch 1
Remote control box 1
Fuses: T2A, T1A, T500mA, F1.25A, F1A, F8A 1 for each
Fuses: F15A, T3.15A, F10A 2 for each
Fuse F1A 5
Screw M5x12 8
Washer 2
Lock washer 8
X-ray cassette 15x30 cm
with Kodak Lanex Medium
(not for DDE versions) 1
X-ray films Kodak Ektavision G
(not for DDE versions) 1 box of 10
Service Manual 1
Operator’s Manual 1
Transcan positioning kit (only for Plus versions) 1
Quick reference guide 2
Crossover Ethernet cable (DDE versions only) 1
Cat.5 Ethernet cable (DDE versions only) 1
VixWin CD-rom (DDE versions only) 1
Ceph arm
Assy nasion 1
Ear plugs 2
Hygienic bags for ear plug 280
Counterweight 1
Additional counterweight (DDE versions only) 2
Soft tissue filter (not for DDE versions) 1
Lead plate 18x24 HA (not for DDE versions) 1
Lead plate 24x30 VS (not for DDE versions) 1
Lead plate H18 (DDE versions only) 1
Lead plate H24 (DDE versions only) 1
X-ray cassette 18x24 cm
with Kodak Lanex Regular
(not for DDE versions) 1
Screw M3x8 2
Lock washer 2
(04.0)E
