ORTHORALIX 9200 Service Manual
B-5
Gendex Dental Systems 4519-190-71193-7
B.5.2 Installing the column on the wall
To take out the column from the crate and transport it on the
desired installation site, two ropes are provided. Use adeguate
gloves to protect the hand.
The column is heavier than 20 kg and so during the
installation it must be handled with care by three
men, avoiding any risk of injury.
To install the column on the wall proceed as follows:
1. Position the column horizontally on the floor.
2. Raise it and place on the desired installation site.
(03.0)E
