Genesis Instant Technical Manual

4.3 Test Menu
This menu allows the engineer to test individual
components and switch inputs to ensure correct
operation. On entry into the Test menu the LCD
will display the screen as shown.
N.B. The Grinder and Teapot Assembly Test
options are only displayed on espresso machines.
4.3.1 Cup Mechanism
This sub menu allows the engineer to test the operation of the cup drop unit
and replicates the function of the Cup Test (
button 7) on the Service Keypad
(see page 69).
1. Press the ↵ (Edit) key twice to display the
test screen followed by the START button
on the drink selection keypad. The cup
drop unit will dispense a cup indicated by
the screen opposite.
2. Pressing the X (Exit) key twice will return
to the main test menu screen.
4.3.2 Hot Vend
Upon entry into this menu the LCD will display
the screen as shown. From this menu screen
the engineer can test for the correct of auger
and whipper motors along with the dispense
valves fitted to the heater tank.
Auger: This sub menu allows the engineer to test for correct operation of
each individual ingredient motor fitted to the machine. Press the ↵ (Edit) key to
display the test screen which indicates the number of motors fitted to the
machine.
N.B. Testing the ingredient motor causes the ingredient canister auger to turn.
Remove canisters before carrying out this test sequence. DO NOT place
ingredient canisters on the floor. Refit correctly after carrying out the test.
1. To test an ingredient motor, e.g. number
1, press the corresponding button on the
drink selection keypad. The selection will
be highlighted as shown and the motor will
operate for 3 seconds. Repeat this
operation to test additional ingredient
motors.
Test Cup Mech anis m 1
Status
Press S TOP To Abort
Disp ensi ng
Hot Vend
Auger
Whipper
Valve
Auger
Auger Number
Press Any Number
1 2 3 4 5 6 7
Test
Press ED IT to Sel ect
Cup Mec hanis m
Hot Vend
Test Dispense Head
Switches & Senso rs
Test Vend Withou t Cups
Test Vend
Grinder
Teapot Assembly Te st
Displa y
Keypad Test
Technical Manual
27
