46
Towing attachments (optional)
Choose the towing attachment to suit the type of trailer or implement towed, in
compliance with the current laws in force.
Ease of driving the tractor also depends on correct use and height adjustment of the
towing attachment.
WARNING: The tractor could tip up if the towing attachment is set in the highest
position.
Keep the drawbar as horizontal as possible when four-wheel drive is used.
Front tow hook (optional)
The tractor can be equipped with a front
tow hook for emergency manoeuvres with
the trailer or for towing the actual tractor
itself.
“Category B” tow hook (optional)
The tractor can be equipped with a rear tow
hook of the “CUNA CAT. B” type for towing
trailers with one or two axles.
To adjust the height of the tow hook:
• remove the pins
• position the hook as shown in the figure
• fix the pins in place
“EEC Category” tow hook (optional)
The tractor can be equipped with the “EEC”
type of rear tow hook for towing trailers with
one or two axles.
To adjust the height of the hook:
• remove the pins
• position the hook as shown in figure
• fix the pins in place
