56
Dry air filter
WARNING: Stop the engine and wait until it has cooled down
before proceeding with any servicing operations.
Clean
50
Clean drain valve A when required, or at
least once a week.
Clean the filter whenever the warning light
comes on or when necessary, after
evaluating the environmental conditions in
which the machine works (dusty, dry, etc.).
Proceed as described below:
• release and remove the cover.
• remove the external filter.
• blow a jet of compressed air (maximum
pressure 3 BAR) from the inside
towards the outside.
• fit the filter back into its housing.
• close with the cover, with the drain valve
in the lowest position.
DO NOT remove the internal safety filter
(it must neither be cleaned nor
damaged).
Replace
300
Replace the external filter when required, or at least after every 300 h service.
Replace the internal safety filter when required, or at least once a year.
