Hardi NAVIGATOR 6000 User Manual

8 - Technical specifications
105
Weight (cont.)
Navigator 4000 with Delta Force boom
Navigator 6000 with Delta Force boom
Wheel and Axle Dimensions
* below wheel axle
N/A: Not Applicable
Empty tank Full tank*
Boom
Width
Folded in transport Unfolded To ta l
Weight
Folded in transport Unfolded To ta l
Weight
Axle load Hitch load Axle load Hitch load Axle load Hitch load Axle load Hitch load
90 ft. DTZ 7546 836 8547 -165 8382 15664 3722 16665 2721 19386
100 ft. DTZ 7612 869 8590 -209 8481 15730 3755 16808 2677 19485
120 ft. DTZ 9379 803 10934 -752 10182 17497 3689 19052 2134 21186
132 ft. DTZ 9368 814 10934 -752 10182 17486 3700 19052 2134 21186
All weights in pounds (lbs)
*Main tank capacity: 1200 gal (4542 L), Rinse tank capacity: 122 gal (460 L), filled with water
Empty tank Full tank*
Boom
Width
Folded in transport Unfolded To ta l
Weight
Folded in transport Unfolded To ta l
Weight
Axle load Hitch load Axle load Hitch load Axle load Hitch load Axle load Hitch load
90 ft. DTZ 9548 1170 10571 147 10718 20152 4910 21175 3887 25062
100 ft. DTZ 9614 1203 10714 103 10817 20218 4943 21318 3843 25161
120 ft. DTZ 11381 1137 12958 -440 12518 21985 4877 23562 3300 26862
132 ft. DTZ 11370 1148 12958 -440 12518 21974 4888 23562 3300 26862
All weights in pounds (lbs)
*Main tank capacity: 1600 gal (6056 L), Rinse tank capacity: 122 gal (460 L), filled with water
Sprayer model Wheel 60” fixed axle 120” fixed axle 60”-120” adj. axle 60”-90” adj. axle Clearance*
3000/3500/4000 320/90 R46 61” 120” 61”-120” N/A 31”
3000/3500/4000 380/90 R46 N/A 120” 64”-120” N/A 31”
3000/3500/4000 320/90 R50 N/A N/A N/A 61”-90” 30”
6000 320/90 R50 N/A 120” N/A 61”-90” 30”
6000 380/90 R46 N/A 120” N/A 64”-90” 28”
6000 480/80 R46 N/A 120” N/A 68”-90” 31”
