Hayward HRSN2 series User Manual

USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
HRSLCSSPLMNTIOM Rev A
Page 33 of 42
Hayward Flow Control
1-888-HAY-INDL (1-888-429-4635)
www.haywardowcontrol.com
MODEL A
in/mm
A'
in/mm
B
in/mm
C
in/mm
D
in/mm
E
in/mm
F
in/mm
G*
in/mm
H
in/mm
J*
in/mm
K*
in/mm
L
in/mm
WEIGHT
lbs/kg
HRCK2A
on/off - LV 6.38 / 162
4.93/125 2.20/56 1.40/36 4.22/107 6.63/170 3.25/83 0.551/14 0.78/20
(4) M6-1.0 X 18mm Deep
F05 /
1.969/50
- 11.3/5.1
Mod - LV 7.56 / 192 (4) M8-1.25 X 20mm Deep
F07 /
2.756/70
HRCK2B
on/off - LV 7.40 / 188
4.93/125 2.20/56 2.32/59 4.22/107 6.63/170 4.25/108 0.551/14 0.78/20
(4) M6-1.0 X 18mm Deep
F05 /
1.969/50
2.5/63
12 turns
90°
11.3/5.1
Mod - LV 8.58 / 218 (4) M8-1.25 X 20mm Deep
F07 /
2.756/70
HRCK2R
on/off - LV 6.38 / 162
4.93/125 2.20/56 1.40/36 4.22/107 6.63/170 3.25/83 0.551/14 0.78/20
(4) M6-1.0 X 18mm Deep
F05 /
1.969/50
- 11.3/5.1
Mod - LV 7.56 / 192 (4) M8-1.25 X 20mm Deep
F07 /
2.756/70
HRCK2S
on/off - LV 7.40 / 188
4.93/125 2.20/56 2.32/59 4.22/107 6.63/170 4.25/108 0.669/17 0.78/20
(4) M6-1.0 X 18mm Deep
F05 /
1.969/50
2.5/63
14 turns
90°
11.3/5.1
Mod - LV 8.58 / 218 (4) M8-1.25 X 20mm Deep
F07 /
2.756/70
DIMENSIONS
Note: Handwheel rotates CW to drive Output shaft CW
HRSN2A/2R (NO HANDWHEEL) HRSN2B/2S (WITH HANDWHEEL OVERRIDE)
COVER REMOVAL
CLEARANCE
COVER REMOVAL
CLEARANCE
ON/OFF HEIGHT DIM MODULATING HEIGHT DIM ON/OFF HEIGHT DIM MODULATING HEIGHT DIM
COVER REMOVAL
CLEARANCE
MECHANICAL DATA
DIMENSIONAL DATA
HRCK2A~2S
