Local Control Stations (LCS) provide a means to select Local or Remote control of a valve or damper actuator.
There are four different types of LCS offered on the HRS series actuators. Each of these four types provide unique
capabilities and human-machine interface.
This supplemental Guide is to be utilized in conjunction with the
actuator IOM. This document differs from the actuator IOM.
This guide will provide necessary wiring diagrams which will differ
from those provided in the actuator IOM itself. You MUST utilize the
wiring diagrams provided in this supplement.
Dimensional Data will differ from that provided in the actuator IOM.
Type CK – Key/Knob type. This is an IP65 type round enclosure that is integral to
the actuator housing. It employs a key switch for the Mode select, a knob switch
for Move commands, and three LED indicators indicating Power, Open and Closed
positions. This version is available on HRSN2 thru HRSN6 Series 24v, 120v & 230v On/
Off actuators.
Type CP – Push Button type. This is an IP67 type round enclosure that is integral to
the actuator housing. This model utilizes push buttons (press-press) to select Remote/
Local Mode, Open/Stop/Close Mode, and LED indicators to show Power, Running
Open and Fully Open, Running Closed and Fully Closed positions. This version is
available on HRSN3 thru HRSN6 Series 24v, 120v & 230v On/Off and Proportional
Control actuators.
Type CL – LED type. This is an IP67 rectangular enclosure integral with the actuator
housing. This model has non-intrusive magnetic type knob switches for Mode and
Position control. This version also employs an LED panel mounted behind glass with
indicators for Open, Close, Remote, Local and Fault. This version is available on HRSN3
thru HRSN6 Series 24v, 120v & 230v On/Off and Proportional Control actuators.
Type CD – LCD type. This is an IP67 rectangular enclosure integral with the actuator
housing. This model has non-intrusive magnetic type knob switches for Mode and
Position control. This version utilizes a monochrome (blue) LCD panel that provides
graphic information regarding the status of the actuator. Its main feature is a large
% display in the center of the screen which shows the position of the actuator as a
function of % of full OPEN. The numeric display ashes when the actuator is moving.
There are UP and DN arrows showing direction of travel.
The lower line of text in the display shows mode of operation, normal status, fault
status, and torque switch trips in their respective directions. There are also LED
indicators above the screen that show Local, Remote, Open and Closed functions.
This version is available on HRSN3 thru HRSN6 Series 24v, 120v & 230v On/Off and
Proportional Control actuators
