ACTUATOR OPTIONS
Depending on the options required you can efciently select the level of actuator and wiring diagram you require.
Control Voltage Actuator Range* Torque Switches** Local Control Wiring Diagram Page
On/Off 24VDC/VAC HRCK2A~6A XTS/TS LCS CK
6
On/Off 120/230VAC HRCK2A~6A XTS/TS LCS CK
6
On/Off 24VDC/VAC HRCP3A~6A XTS/TS LCS CP
6
On/Off 120/230VAC HRCP3A~6A XTS/TS LCS CP
6
Mod 24VDC/VAC HRCK2A~6A XTS/TS LCS CK
7
Mod 120/230VAC HRCK2A~6A XTS/TS LCS CK
7
Mod 24VDC/VAC HRCP3A~6A XTS/TS LCS CP
7
Mod 120/230VAC HRCP3A~6A XTS/TS LCS CP
7
On/Off 24VDC/VAC HRCL3A~6A XTS/TS LCS CL
8
On/Off 120/230VAC HRCL3A~6A XTS/TS LCS CL 8
On/Off 24VDC/VAC HRCD3A~6A XTS/TS LCS CD 8
On/Off 120/230VAC HRCD3A~6A XTS/TS LCS CD 8
Mod 24VDC/VAC HRCL3A~6A XTS/TS LCS CL 9
Mod 120/230VAC HRCL3A~6A XTS/TS LCS CL 9
Mod 24VDC/VAC HRCD3A~6A XTS/TS LCS CD 9
Mod 120/230VAC HRCD3A~6A XTS/TS LCS CD
9
Below are Terms and Denitions used throughout this manual.
1. XTS/TS product manufactured without/with Torque Switches.
2. LCS product manufactured with attached Local Control Station.
* The only LCS available in the HRSN2A~2S range is the LCS CK.
** Some frame sizes are available only with TS (no XTS option).
