HIKVISION DS-7108HGHI-F1 User Manual

Digital Video Recorder User Manual
244
Contrast and Saturation for the IP cameras. You can also click Restore to set the
parameters to the default settings.
Step 7 You can click Copy to copy the image settings of the current camera to other cameras.
Step 8 Click Apply to save the settings.
15.3.2 Configuring Camera Parameters Settings
This section is applicable to -F series DVR.
Step 1 Enter the Image Settings interface.
Menu > Camera > Image
Step 2 Select the Camera Parameters Settings tab.
Figure 15-7 Camera Parameters Settings
Step 3 Select the Camera from the dropdown list.
Step 4 Adjust the camera parameters. The parameters include Day to Night Sensitivity, Night to
Day Sensitivity and IR Light Brightness for the analog cameras. You can also click Default to
set the parameters to the default settings.
Step 5 You can click Copy to copy the parameters of the current camera to other analog cameras.
Step 6 Click Apply to save the settings.

HIKVISION DS-7108HGHI-F1 Specifications

General

Voltage	12 V
Certification	CE
Product color	White
Channels quantity	8 channels
Maximum frame rate	30 fps
Audio output channels	2.0 channels
Audio formats supported	G.711
Multi-display supported	Yes
Network connection type	RJ-45
Maximum video resolution	1920 x 1080 pixels
Video compression formats	H.264
Playback resolutions supported	1920 x 1080, 1280 x 1024, 1280 x 720, 1024 x 768
Video in	BNC
Video out	HDMI, VGA
Audio input	1x RCA
BNC input ports	8
USB 2.0 ports quantity	2
Number of users	128 user(s)
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik Cloud P2P, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP, HTTPS
HDD interface	Serial ATA
Maximum HDD capacity	6000 GB
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Power requirements	DC
Power consumption (typical)	12 W

Weight and Dimensions

Weight	800 g
Dimensions (WxDxH)	200 x 200 x 45 mm
