HIKVISION DS-7108HGHI-F1 User Manual

Digital Video Recorder User Manual
269
(HDTVI or CVBS). The above information is for reference only. Please refer to the specific
configuration of the device.
18.1.3 DS-7200HGHI-E2
Model
DS-7208HGHI-E2
DS-7216HGHI- E2
Video/
Audio input
Video compression
H.264+/H.264
Analog and HDTVI
video input
8-ch
16-ch
BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron
connection
Supported camera
types
720p25, 720p30, CVBS
IP video input
2-ch
Up to 1080p resolution
Audio compression
G.711u
Audio
input/Two-way
audio in
1-ch, RCA (2.0 Vp-p, 1 KΩ)
Video/
Audio output
HDMI/VGA output
1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz,
1024 × 768/60Hz
Encoding resolution
720p/VGA/WD1/4CIF/CIF
Frame rate
Main stream: 720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps
(N)
Sub-stream:
4CIF/2CIF@6fps;
CIF/QVGA/QCIF@25fps (P)/30fps (N)
Video bit rate
32 Kbps to 4 Mbps
Audio output
1-ch, RCA (Linear, 1 KΩ)
Audio bit rate
64 Kbps
Dual-stream
Support
Stream type
Video, Video & Audio
Synchronous
playback
8-ch
16-ch

HIKVISION DS-7108HGHI-F1 Specifications

General

Voltage	12 V
Certification	CE
Product color	White
Channels quantity	8 channels
Maximum frame rate	30 fps
Audio output channels	2.0 channels
Audio formats supported	G.711
Multi-display supported	Yes
Network connection type	RJ-45
Maximum video resolution	1920 x 1080 pixels
Video compression formats	H.264
Playback resolutions supported	1920 x 1080, 1280 x 1024, 1280 x 720, 1024 x 768
Video in	BNC
Video out	HDMI, VGA
Audio input	1x RCA
BNC input ports	8
USB 2.0 ports quantity	2
Number of users	128 user(s)
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik Cloud P2P, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP, HTTPS
HDD interface	Serial ATA
Maximum HDD capacity	6000 GB
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Power requirements	DC
Power consumption (typical)	12 W

Weight and Dimensions

Weight	800 g
Dimensions (WxDxH)	200 x 200 x 45 mm
