HIKVISION DS-7108HGHI-F1 User Manual

Digital Video Recorder User Manual
267
(W × D × H)
inch)
Weight
(without HDD)
≤ 0.8 kg (1.8 lb)
≤ 1.2 kg (2.6 lb)
Each two video channels are grouped in sequence, e.g., CH01 and CH02, CH03 and CH04...; and
each two channels in the same group must be connected with the same type of video source
(HDTVI or CVBS). The above information is for reference only. Please refer to the specific
configuration of the device.
18.1.2 DS-7200HGHI-E1
Model
DS-7204HGHI-E1
DS-7208HGHI-E1
DS-7216HGHI-E1
Video/
Audio input
Video
compression
H.264+/H.264
Analog and
HDTVI video
input
4-ch
8-ch
16-ch
BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron
connection
Supported
camera types
720p25, 720p30, CVBS
IP video input
1-ch
2-ch
Up to 720p
resolution
Up to 1080p resolution
Audio
compression
G.711u
Audio
input/Two-way
audio input
1-ch, RCA (2.0 Vp-p, 1 KΩ)
Video/
Audio output
HDMI/VGA
output
1920 × 1080/60Hz,1280 × 1024/60Hz, 1280 × 720/60Hz, 1024
× 768/60Hz
Encoding
resolution
720p/VGA/WD1/4CIF/CIF
Frame rate
Main stream: 720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)
Sub-stream:
2CIF@6fps;
Sub-stream:
4CIF/2CIF@6fps;

HIKVISION DS-7108HGHI-F1 Specifications

General

Voltage	12 V
Certification	CE
Product color	White
Channels quantity	8 channels
Maximum frame rate	30 fps
Audio output channels	2.0 channels
Audio formats supported	G.711
Multi-display supported	Yes
Network connection type	RJ-45
Maximum video resolution	1920 x 1080 pixels
Video compression formats	H.264
Playback resolutions supported	1920 x 1080, 1280 x 1024, 1280 x 720, 1024 x 768
Video in	BNC
Video out	HDMI, VGA
Audio input	1x RCA
BNC input ports	8
USB 2.0 ports quantity	2
Number of users	128 user(s)
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik Cloud P2P, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP, HTTPS
HDD interface	Serial ATA
Maximum HDD capacity	6000 GB
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Power requirements	DC
Power consumption (typical)	12 W

Weight and Dimensions

Weight	800 g
Dimensions (WxDxH)	200 x 200 x 45 mm
