Digital Video Recorder User Manual
271
18.1.4 DS-7100HGHI-F1
BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
1080P25, 1080P30, 720p25, 720p30
Audio
input/Two-w
ay audio
input
1-ch, RCA (2.0 Vp-p, 1 KΩ)
1-ch, 1920 × 1080/60Hz,1280 × 1024/60Hz, 1280 × 720/60Hz,
1024 × 768/60Hz
When 1080p Lite mode not enabled: 720p/WD1/4CIF/VGA/CIF
When 1080p Lite mode enabled:
1080p lite/720p/WD1/4CIF/VGA/CIF
Main stream:
When 1080p Lite mode not enabled:
For 720p stream access: 720p/WD1/4CIF/VGA/CIF@25fps
(P)/30fps (N)
When 1080p Lite mode enabled:
1080p lite/720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N)
Sub-stream:
2CIF@6fps;
CIF/QVGA/QCIF@
25fps (P)/30fps (N)
Sub-stream:
4CIF/2CIF@6fps;
CIF/QVGA/QCIF@25fps (P)/30fps (N)
