18.1.6 DS-7200HGHI-F2
Model
DS-7208HGHI-F2
DS-7216HGHI- F2
Video/Audio
input
Video compression
H.264+/H.264
Analog video input
8-ch
16-ch
BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron
connection
HDTVI input
1080P25, 1080P30, 720p25, 720p30
AHD input
720p25, 720p30
HDCVI input
720p25, 720p30
CVBS input
Support
IP video input
2-ch
Up to 1080p resolution
Audio compression
G.711u
Audio
input/Two-way
audio input
1-ch, RCA (2.0 Vp-p, 1 KΩ)
Video/Audio
output
HDMI/VGA output
1-ch, 1920 × 1080/60Hz,1280 × 1024/60Hz, 1280 ×
720/60Hz, 1024 × 768/60Hz
Encoding
resolution
When 1080p Lite mode not enabled:
720p/WD1/4CIF/VGA/CIF
When 1080p Lite mode enabled:
1080p lite/720p/WD1/4CIF/VGA/CIF
Frame rate
Main stream:
When 1080p Lite mode not enabled:
For 720p stream access:
720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N)
When 1080p Lite mode enabled:
1080p lite/720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N)
Sub-stream:
4CIF/2CIF@6fps; CIF/QVGA/QCIF@25fps (P)/30fps (N);

HIKVISION DS-7108HGHI-F1 Specifications

General

Voltage	12 V
Certification	CE
Product color	White
Channels quantity	8 channels
Maximum frame rate	30 fps
Audio output channels	2.0 channels
Audio formats supported	G.711
Multi-display supported	Yes
Network connection type	RJ-45
Maximum video resolution	1920 x 1080 pixels
Video compression formats	H.264
Playback resolutions supported	1920 x 1080, 1280 x 1024, 1280 x 720, 1024 x 768
Video in	BNC
Video out	HDMI, VGA
Audio input	1x RCA
BNC input ports	8
USB 2.0 ports quantity	2
Number of users	128 user(s)
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik Cloud P2P, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP, HTTPS
HDD interface	Serial ATA
Maximum HDD capacity	6000 GB
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Power requirements	DC
Power consumption (typical)	12 W

Weight and Dimensions

Weight	800 g
Dimensions (WxDxH)	200 x 200 x 45 mm
