Digital Video Recorder User Manual
85
4) Click , and the message box for channel information pops up.
Figure 5-14 Motion Detection Settings
5) Select the channels which you want the motion detection event to trigger recording.
6) Click Apply to save the settings.
7) Click OK to back to the upper level menu.
8) Exit the Motion Detection menu.
Step 3 Configure the schedule.
Please refer to the step 4 of Chapter 5.2 Configuring Recording Schedule, while you may
choose Motion as the record type.
5.4 Configuring Alarm Triggered Recording and Capture
Purpose
Follow the procedure to configure alarm triggered recording or capture.
Step 1 Go to Menu > Configuration > Alarm > Alarm Input.
Figure 5-15 Alarm Settings- Alarm Input
Step 2 Select Alarm Input No.
Step 3 Input Alarm Name.
Step 4 Select N.O (normally open) or N.C (normally closed) for alarm type.
Step 5 Check the checkbox of Enable to enable alarm.
