HIKVISION DS-K3G200LX-R/Dm55 User Manual

Appendix B. Buon Conguraon Descripon
Refer to the table below for device conguraon via buon on the lane control board.
Level-1 Conguraon No. Descripon Level-1 Conguraon No. and
Funcons
3 Passing Mode 1-Both sides under control
Note
By default, 1 will be displayed
on the display screen.
2-Entrance under control; exit
prohibited
3-Entrance under control; exit
free
4-Both sides free
5-Entrance free; exit under
control
6-Entrance free; exit prohibited
7-Both sides prohibited
8-Entrance prohibited; exit
under control
9-Entrance prohibited; exit free
4
Memory Mode 1-Disable
2-Enable
Note
By default, 2 will be displayed
on the display screen.
9 Enter Duraon 5-5s，6-6s，7-7s, ..., 60-60s
Note
By default, 5 will be displayed
on the display screen.
10 Exit Duraon 5-5s，6-6s，7-7s, ..., 60-60s
DS-K3G200(L)X Series Tripod Turnsle
70
