User Manual of Network Speed Dome
© Hikvision Digital Technology Co., Ltd. All Rights Reserved.
25
Chapter 4 Live View
4.1 Power-up Action
After the power is applied, the speed dome will perform self-test actions. It begins
with lens actions and then pan and tilt movement. After the power-up self-test
actions, the information as shown in Figure 4-1 will be displayed on screen for 40
seconds.
The System Information displayed on the screen includes the dome address, protocol,
version and other information. The COMMUNICATION refers to the baud rate, parity,
data bit and stop bit of the dome. e.g., “2400, N, 8, 1” indicates the dome is
configured with the baud rate of 2400, no parity, 8 data bits and 1 stop bit.
ADDRESS 0
COMMUNICATION 0000,0,0,0
SOFTWARE VERSION V000
CAMERA VERSION
LANGUAGE ENGLISH
Figure 4-1 Power-up information
4.2 Live View Page
Purpose:
The live video page allows you to view live video, capture images, realize PTZ control,
set/call presets and configure video parameters.
Log in the network speed dome to enter the live view page, or you can click
on the menu bar of the main page to enter the live view page.
