VersaCare® Bed User Manual (161956 REV 2) 47
Patient Helper Adapter Bracket (P844G48)
The patient helper adapter bracket (P844G48) is for use with
the patient helper available from Orthopedic Systems, Inc.
The P844G48 has the support tube built into the frame
assembly.
Refer to the equipment manufacturer’s instructions for
installation procedures.
WARNING:
Do not exceed the load capacity of the Patient Helper Adapter Bracket. If the
Patient Helper Adapter Bracket is overloaded, personal injury or equipment
damage could occur.
The safe working load of the Patient Helper Adapter Bracket is 165 lb (75 kg).
Fracture Frame Adapter Bracket
(P3211B)
WARNING:
The sleep deck moves independently of bed
frame. Failure to account for the sleep deck
movement when using fracture frames
and/or traction equipment can cause serious
injury or death.
The fracture frame adapter bracket (P3211B) is for use when setting up fracture frame
traction equipment.
For safe installation and operation, refer to the equipment manufacturer’s installation and
operation instructions.
WARNING:
Do not exceed the load capacity of the Fracture Frame Adapter Bracket. If the
Fracture Frame Adapter Bracket is overloaded, personal injury or equipment
damage may occur.
The safe working load of the Fracture Frame Adapter Bracket is 200 lb (90 kg).

Hill-Rom VersaCare Bed Specifications

General

Type	Hospital Bed
Application	Acute Care
Point-of-Care Controls	Yes
X-Ray Cassette Sleeve	Optional
CPR Release	Yes
Battery Backup	Yes
Bed Width	36 inches
Safe Working Load	500 lb (227 kg)
Side Rail Options	Full
