Installation MACH 1000
Release 04 12/2015
1.5 Display elements
After the supply voltage is set up, the software starts and initializes itself.
Afterwards, the device performs a self-test. During this process, various
LEDs light up. The process takes around 60 seconds.
Figure 7: Display elements of MACH 1000, device variants with ports on the front
1 - Device status display elements
2 - Port status display elements
Figure 8: Display elements of MACH 1000, device variants with ports on the back
1 - Device status display elements
2 - Port status display elements for up to 4 Gigabit Ethernet ports and
up to 20 Fast Ethernet ports
3 - Diagnosis port with display element
USB
V.24
MACH 1000
P
StandByRM
FAULT
R1
R2
1
2
P
StandByRM
FAULT
R1
R2
ETHERNET Service Port
1
3
5
7
9
11
13
15
17
19
21
23
2
4
6
8
10
12
14
16
18
20
22
24
21 3
