Installation MACH 1000
Release
04
12/2015
Applies to software release 06.0.00 and higher:
Applies to software releases previous to 06.0.00:
Applies to software release 06.0.00 and higher:
If the manual setting is active on the signal contact, then the error display is
independent of the setting of the signal contact.
1.5.2 Port state
The green and yellow LEDs at the individual port display port-related
information. During the boot phase, these LEDs are used to display the
status of the boot procedure.
LED Display Color Activity Meaning
FAULT Signal contact 1 Red Lights up The signal contact is open - it is reporting a
detected error.
None The signal contact is closed - it is not reporting
any detected errors.
Duplicate IP
detection
Red flashes 4
times a
period
Reports an IP conflict.
LED Display Color Activity Meaning
R1 Signal contact 1 Yellow Lights up The signal contact is closed in manual operation.
None The signal contact is open in manual operation.
R2 Signal contact 2 Yellow Lights up The signal contact is closed in manual operation.
None The signal contact is open in manual operation.
LED Display Color Activity Meaning
R1 Signal contact 1 Yellow Lights up The signal contact is open.
None The signal contact is closed.
R2 Signal contact 2 Yellow Lights up The signal contact is open.
None The signal contact is closed.
LS - data, link status (one green/yellow LED or one green and one yellow LED)
Not glowing No valid connection.
Glowing green Valid connection.
Flashing green (1 time a period) Port is switched to stand-by.
Flashing green (3 times a
period)
Port is switched off.
Flashing yellow Data reception.
