32
Installation RSPE30/32/35/37
Release 16 04/2019
In accordance with IEEE 802.3af and IEEE 802.3at:
 Endpoint PSE
 Alternative A.
1.6 Display elements
After the supply voltage is set up, the Software starts and initializes the
device. Afterwards, the device performs a self-test. During this process,
various LEDs light up.
1.6.1 Device state
These LEDs provide information about conditions which affect the operation
of the whole device.
LED Display Color Activity Meaning
Power Supply voltage — none Supply voltage is too low
yellow lights up Device variants with redundant power
supply:
Supply voltage 1 or 2 is on
flashes 4 times
a period
Software update is running. Maintain the
power supply.
green lights up Device variants with redundant power
supply:
Supply voltage 1 and 2 is on
Device variants with single power supply:
Supply voltage is on
ACA Storage medium
ACA21
ACA31
— none ACA storage medium not connected
green lights up ACA storage medium connected
flashes 3 times
a period
Device writes to/reads from the storage
medium
yellow lights up ACA storage medium inoperative
RM Ring Manager — none No redundancy configured
green lights up Redundancy exists
flashes 1 time
a period
Device is reporting an incorrect
configuration of the RM function
yellow lights up No redundancy exists
Status
RM
ACA
Power
