Installation RSPE30/32/35/37
Release
16
04/2019
33
1.6.2 Media module status
Device variants RSPE30 and RSPE35
1 LED is located on the upper part of the media module.
This LED provides information on the supply voltage status of the media
module.
Device variants RSPE32 and RSPE37
2 LEDs are located on the upper part of the media module.
These LEDs combined provide information on the supply voltage status
and the PoE status of the media module.
Status Device Status — none Device is starting and/or is not ready for
operation.
green lights up Device is ready for operation.
Characteristics can be configured
red lights up Device is ready for operation.
Device has detected at least one error in
the monitoring results
flashes 1 time
a period
The boot parameters used when the
device has been started differ from the
boot parameters saved.
Start the device again.
flashes 4 times
a period
Device has detected a multiple IP address
LED Display Color Activity Meaning
Power Supply voltage — none Media module is inoperative
green lights up Supply voltage is on
LED Display Color Activity Meaning
Power Supply voltage — none Media module is inoperative
green lights up Voltage supply to the media module is on
Voltage supply to the PoE port is on
yellow lights up PoE voltage is missing or is too low
LED Display Color Activity Meaning
