54
Installation RSPE30/32/35/37
Release 16 04/2019
6.2 Removing an SFP transceiver (optional)
Figure 8: De-installing SFP transceivers: De-installation sequence
Proceed as follows:
 Open the locking mechanism of the SFP transceiver (1).
 Pull the SFP transceiver out of the slot via the open locking
mechanism (2).
 Close the SFP transceiver with the protection cap (3).
6.3 Removing a media module (optional)
You have the option to remove the media modules while the device is
operating.
Proceed as follows:
 Loosen the 2 screws on the media module.
 Pull the media module out of the slot.
 Seal the media module slot on the device with a cover panel.
See “Accessories” on page 69.
1
2
3
