Hirschmann RSPE30 User Manual

Installation RSPE30/32/35/37
Release 16 04/2019
55
7 Technical data
7.1 General technical data
Dimensions
W × H × D
RSPE30/32/35/37 See “Dimension drawings” on page 59.
Weight Devices with operating
temperature characteristic
value S (standard):
4.6 lb (2.2 kg)
Devices with operating
temperature characteristic
value E and T (extended):
5.5 lb (2.5 kg)
Supply voltage
with the
characteristic
value CC
Connection type 2-pin terminal block
Tightening torque 4.5 lb-in
(0.51 Nm)
Rated voltage DC: 24 V DC ... 48 V DC
Voltage range DC incl.
maximum tolerances:
18 V DC ... 60 V DC
Rated power RSPE30 for DC 0.6 A ... 1.3 A
RSPE35 for DC 0.7 A ... 1.4 A
Power loss buffer >10 ms at 20.4 V DC
Overload current protection on
the device
Non-replaceable fuse
Back-up fuse for each voltage
input
Nominal rating:
Characteristic:
1A
slow blow
Peak inrush current <4 A
Supply voltage
with the
characteristic
value K9
and KK
Connection type 3-pin terminal block
Tightening torque 4.5 lb-in
(0.51 Nm)
Rated voltage range DC: 60 V DC ... 250 V DC
Voltage range DC incl.
maximum tolerances:
48 V DC ... 320 V DC
Rated voltage range AC: 110 V AC ... 230 V AC, 50 Hz ... 60 Hz
Voltage range AC incl.
maximum tolerances:
88 V AC ... 265 V AC, 47 Hz ... 63 Hz
Rated power RSPE30 for AC
for DC
0.25 A ... 0.4 A
0.2 A ... 0.5 A
RSPE35 for AC
for DC
0.25 A ... 0.4 A
0.6 A ... 0.2 A
Power loss buffer > 10 ms at 98 V AC
Overload current protection on
the device
Non-replaceable fuse
Back-up fuse Nominal rating:
Characteristic:
1 A ... 20 A
slow blow
Peak inrush current <3.5 A
