48
Installation RSPE30/32/35/37
Release
16
04/2019
2.7 Operating the device
Relevant for North America:
You find the prescribed tightening torque in chapter:
“General technical data” on page 55
Proceed as follows:
Use screws to secure the connectors to the device.
Enable the supply voltage.
2.8 Connecting data cables
Note the following general recommendations for data cable connections in
environments with high electrical interference levels:
Keep the length of the data cables as short as possible.
Use optical data cables for the data transmission between the buildings.
When using copper cables, provide a sufficient separation between the
power supply cables and the data cables. Ideally, install the cables in
separate cable channels.
Verify that power supply cables and data cables do not run parallel over
longer distances. If reducing the inductive coupling is necessary, verify
that the power supply cables and data cables cross at a 90° angle.
Use SF/UTP cables as per ISO/IEC 11801:2002.
Connect the data cables according to your requirements.
WARNING
ELECTRIC SHOCK
Before connecting the electrical wires, always verify that the requirements
listed are complied with.
See “Requirements for connecting electrical wires” on page 7.
Ground the device before connecting any other cables.
Failure to follow this instruction can result in death, serious injury, or
equipment damage.
