68
Installation RSPE30/32/35/37
Release
16
04/2019
7.5 Power consumption/power output
The order numbers correspond to the product codes of the devices.
See “Device name and product code” on page 21.
7.6 Scope of delivery, order numbers and
accessories
Scope of delivery
Device name Maximum
power
consumption
a
a. You can find the total power consumption specifications for basic modules that are to be
installed in the “User Manual Installation RSPM”.
Power output
RSPE30 16 W 55 Btu (IT)/h
RSPE32 including 124 W PoE output power 151 W 92 Btu (IT)/h
RSPE 35 18 W 61 Btu (IT)/h
RSPE37 including 124 W PoE output power 153 W 98 Btu (IT)/h
RSPM20-4Z64Z6... 9 W 31 Btu (IT)/h
RSPM20-4T14T1... 2 W 7 Btu (IT)/h
RSPM20-4T14Z6... 5 W 17 Btu (IT)/h
RSPM22-4T14T1... including PoE output power 2 W 7 Btu (IT)/h
RSPM22-4T14Z6... including PoE output power 5 W 17 Btu (IT)/h
Number Article
1× Device
1 × 2-pin terminal block for signal contact
1 × 3-pin terminal block for the supply voltage
(only for device variants featuring supply voltage with characteristic value K9)
2 × 3-pin terminal block for the supply voltage
(exclusively for device variants featuring supply voltage with characteristic
value KK)
2 × 2-pin terminal block for the supply voltage
(only for device variants featuring supply voltage with characteristic value CC
or PP)
1 × General safety instructions
