Hitachi Advanced Server HA820 G2 User Guide 122
CAUTION:
When handling the heatsink, always hold it along the top and bottom of the fins. Holding it from the sides
can damage the fins.
CAUTION:
To prevent possible server malfunction and damage to the equipment, multiprocessor configurations must
contain processors with the same part number.
CAUTION:
If installing a processor with a faster speed, update the system ROM before installing the processor. To
download firmware and view installation instructions, see the
Hitachi Vantara website
.
CAUTION: THE CONTACTS ARE
VERY
FRAGILE AND EASILY DAMAGED.
To avoid damage to the socket or
processor, do not touch the contacts.
3.
Power down the server.
4.
Remove all power:
a.
Disconnect each power cord from the power source.
b.
Disconnect each power cord from the server.
5.
Do one of the following:
a.
Extending the server from the rack.
b.
Removing the server from the rack.
6.
Remove the access panel.
7.
If installing processors over 150W, install high performance fans.
8.
Install the processor heatsink assembly:
a.
Remove the dust cover from the socket.
b.
Identify the front of server label on the heatsink.
9.
Align the assembly with the socket and gently lower it down until it sits on the socket.
Be sure the latches lock the heatsink into place. The heatsink and socket are keyed.
The processor will only install one way.
