Hitachi Advanced Server HA820 G2 User Guide 43
• Remove the midplane drive cage:
a. Disconnect all cables.
b. Remove all drives.
Be sure to note the location of each drive.
c. Remove the drive cage.
A 4LFF version is shown.
CAUTION:
Do not drop the drive cage on the system board. Dropping the drive cage on the system board
might damage the system or components. Remove all drives and use two hands when installing or
removing the drive cage.
