Hitachi YUTAKI S Series Installation And Operation Manual

33
PMEN0643 rev.0 - 04/2023
6
ELECTRICAL CONNECTION
ELECTRICAL AND CONTROL SETTINGS
6.2.2 Minimum requirements of the protecon devices
! CAUTION
• Ensure specically that there is an Earth Leakage Breaker (ELB) installed for the units (outdoor
and indoor unit).
• If the installaon is already equipped with an Earth Leakage Breaker (ELB), ensure that its rated
current is large enough to hold the current of the units (outdoor and indoor unit).
 NOTE
• Electric fuses can be used instead of magnec Circuit Breakers (CB). In that case, select fuses
with similar rated values as the CB.
• The Earth Leakage Breaker (ELB) menoned on this manual is also commonly known as Residual
Current Device (RCD) or Residual Current Circuit Breaker (RCCB).
• The Circuit Breakers (CB) are also known as Thermal‑Magnec Circuit Breakers or just Magnec
Circuit Breakers (MCB).
Model Power supply
Applicable voltage
Operaon mode
MC
(A)
CB
(A)
ELB
(number of
poles/A/mA)
U max
(V)
U min
(V)
RWM‑(1.5‑3.0)R2E
~ 230V 50Hz 253 207
Without electric heaters
0.6
5
2/40/30
With electric heater 13.7 16
With DHW tank heater 12.6 16
With electric and DHW tank heaters
25.6 32
3N~ 400V
50Hz
440 360
Without electric heaters
0.6
5
4/40/30
With electric heater 5 10
With DHW tank heater 12.6 16
With electric and DHW tank heaters
16.9
20
 NOTE
The data corresponding to DHW tank heater is calculated in combinaon with the domesc hot
water tank accessory “DHWT‑(200/300)S‑3.0H2E”.

Hitachi YUTAKI S Series Specifications

General

Type	Air-to-Water Heat Pump
Refrigerant	R410A
Cooling Capacity	2.5 - 16 kW
Operating Temperature Range (Cooling)	46°C
Indoor Unit Dimensions	Varies by model
Outdoor Unit Dimensions	Varies by model
Noise Level	Varies by model
