HOLOPLOT X1 User Manual

9X1 MD80-S Manual 1.0 en
AUDIO MODULES
HOLOPLOT Audio Modules are 3D Audio-Beamforming
and Wave Field Synthesis loudspeakers with integrated
signal processing and amplication that can be arrayed
horizontally and vertically to create differently sized
HOLOPLOT Matrix Arrays.
The two HOLOPLOT X1 Audio Modules, “Modul 96”
(MD96) and “Modul 80-S” (MD80-S), are targeted at
high-performance audio applications. All HOLOPLOT X1
Audio Modules are identical in width, height, and rigging
system, but differ in depth, weight, and frequency
range. The MD96 is a two-way Audio Module with 96
loudspeaker drivers; the MD80-S is a three-way Audio
Module with 80 loudspeaker drivers and a single sensor-
controlled subwoofer driver.
HOLOPLOT Audio System
In HOLOPLOT Audio Modules, each loudspeaker driver
is individually amplied and controlled by its own Digital
Signal Processor (DSP), enabling ultimate control
over sound. HOLOPLOT Audio Modules are capable of
generating multiple sound elds simultaneously — each
with its own content, equalization, level, shape, and
position — either in a single Audio Module deployment or
as part of a larger HOLOPLOT Matrix Array system.
Each Audio Module provides digital audio connectivity
through Audinate Dante — up to 200 channel-based or
object-based audio content streams can be received by
one Audio Module, processed in parallel, and mapped to,
or panned between multiple sound elds.
HOLOPLOT Audio System
A HOLOPLOT Audio System consists of:
• AUDIO MODULES — 3D Audio-Beamforming and Wave Field Synthesis loudspeakers
• CONTROLLER — a rack-mountable device to manage HOLOPLOT Audio Modules
• SOFTWARE SUITE — for design and simulation, control and monitoring, as well as
authoring of object-based audio content and playback for HOLOPLOT Audio Systems
HOLOPLOT X1
Modul 96
HOLOPLOT X1
Modul 80-S
