Honda Africa Twin CRF1000 2017 User Manual

Tool
The tool kit is stored in the tool box. 2 P. 89
You can perform some roadside repairs, minor
adjustments and parts replacement with the
provided tools.
● Spark plug wrench
● 10 × 14 mm Open end wrench
● 14 × 17 mm Open end wrench
●
Standard/Phillips screwdriver
● Screwdriver handle
● 19 mm Box end wrench
● Fuse puller
The helmet set wire is secured with the rear
fender under the front seat. 2 P. 88
● Helmet set wire
The 5mm hex wrench is located on the
underside of the front seat. 2 P. 88
● 5 mm Hex wrench
20171109154101_32MKK8000_eng_BOOK Page 113 Thursday, November 09 2017 15:56:56 JST
Maintenance
108

Honda Africa Twin CRF1000 2017 Specifications

General

Displacement	998 cc
Horsepower	94 hp
Bore x Stroke	92.0 mm x 75.1 mm
Compression Ratio	10.0:1
Fuel System	PGM-FI electronic fuel injection
Ignition	Full transistorized ignition
Final Drive	Chain
Front Tire	90/90-21
Rear Tire	150/70-18
Fuel Capacity	4.97 gallons
Engine Type	Liquid-cooled, 4-stroke, 8-valve, parallel-twin
Max Power Output	70 kW @ 7, 500 rpm
Torque	98 Nm @ 6, 000 rpm
Transmission	6-speed
Front Suspension	45mm inverted telescopic fork
Rear Suspension	Pro-Link with gas-charged damper, 220mm travel
Front Brake	Dual 310mm wave disc with 4-piston calipers
Rear Brake	256mm hydraulic disc with ABS
Wheelbase	62.0 inches
Seat Height	34.3 / 33.5 inches (adjustable)
Wet Weight	228 kg (503 lbs)
Curb Weight	228 kg (503 lbs)
Kerb Weight	511 pounds
Traction Control	Selectable Torque Control (HSTC)
