Honda Africa Twin CRF1000 2017 User Manual

Side Stand
Checking the Side Stand
1.
Check that the side stand operates
smoothly. If the side stand is stiff or
squeaky, clean the pivot area and
lubricate the pivot bolt with clean grease.
2.
Check the spring for damage or loss of
tension.
3.
CRF1000A/A II
Sit on the motorcycle, shift the
transmission to Neutral, and raise the side
stand.
CRF1000D/D II
Sit on the motorcycle and raise the side
stand.
4.
CRF1000A/A II
Start the engine, pull the clutch lever in,
and shift the transmission into gear.
CRF1000D/D II
Start the engine and press the
D-S
side
of N-D switch to switch the transmission
into D mode.
5.
Lower the side stand all the way. The
engine should stop as you lower the side
stand. If the engine doesn't stop, have
your motorcycle inspected by your dealer.
20171109154101_32MKK8000_eng_BOOK Page 134 Thursday, November 09 2017 15:56:56 JST
Maintenance
129
Side stand spring

Honda Africa Twin CRF1000 2017 Specifications

General

Displacement	998 cc
Horsepower	94 hp
Bore x Stroke	92.0 mm x 75.1 mm
Compression Ratio	10.0:1
Fuel System	PGM-FI electronic fuel injection
Ignition	Full transistorized ignition
Final Drive	Chain
Front Tire	90/90-21
Rear Tire	150/70-18
Fuel Capacity	4.97 gallons
Engine Type	Liquid-cooled, 4-stroke, 8-valve, parallel-twin
Max Power Output	70 kW @ 7, 500 rpm
Torque	98 Nm @ 6, 000 rpm
Transmission	6-speed
Front Suspension	45mm inverted telescopic fork
Rear Suspension	Pro-Link with gas-charged damper, 220mm travel
Front Brake	Dual 310mm wave disc with 4-piston calipers
Rear Brake	256mm hydraulic disc with ABS
Wheelbase	62.0 inches
Seat Height	34.3 / 33.5 inches (adjustable)
Wet Weight	228 kg (503 lbs)
Curb Weight	228 kg (503 lbs)
Kerb Weight	511 pounds
Traction Control	Selectable Torque Control (HSTC)
