Honda Africa Twin CRF1000 2017 User Manual

Engine Oil
Checking the Engine Oil
1.
Place your motorcycle on its side stand on
a firm, level surface.
2.
If the engine is cold, idle the engine for 3
to 5 minutes.
3.
Turn the ignition switch to the (Off)
position and wait for 2 to 3 minutes.
4.
Place your motorcycle in an upright
position on a firm, level surface.
5.
Remove the dipstick and wipe it clean.
6.
Insert the dipstick until it seats, but don't
screw it in.
7.
Check that the oil level is between the
upper level and lower level marks on the
dipstick.
8.
Securely install the dipstick.
20171109154101_32MKK8000_eng_BOOK Page 123 Thursday, November 09 2017 15:56:56 JST
Maintenance
118
Oil fill cap
Upper
level
Lower
level
Dipstick

Honda Africa Twin CRF1000 2017 Specifications

General

Displacement	998 cc
Horsepower	94 hp
Bore x Stroke	92.0 mm x 75.1 mm
Compression Ratio	10.0:1
Fuel System	PGM-FI electronic fuel injection
Ignition	Full transistorized ignition
Final Drive	Chain
Front Tire	90/90-21
Rear Tire	150/70-18
Fuel Capacity	4.97 gallons
Engine Type	Liquid-cooled, 4-stroke, 8-valve, parallel-twin
Max Power Output	70 kW @ 7, 500 rpm
Torque	98 Nm @ 6, 000 rpm
Transmission	6-speed
Front Suspension	45mm inverted telescopic fork
Rear Suspension	Pro-Link with gas-charged damper, 220mm travel
Front Brake	Dual 310mm wave disc with 4-piston calipers
Rear Brake	256mm hydraulic disc with ABS
Wheelbase	62.0 inches
Seat Height	34.3 / 33.5 inches (adjustable)
Wet Weight	228 kg (503 lbs)
Curb Weight	228 kg (503 lbs)
Kerb Weight	511 pounds
Traction Control	Selectable Torque Control (HSTC)
